Review open BIM files
Use the IFC workflow for model inspection where open IFC files are part of coordination.
IFC Viewer inside project context
Open IFC files directly from ArchiMesh project records and review the model with browser tools for navigation, sectioning, visibility, measurement, properties and screenshots.
IFCmodel viewing
Toolsfor review
Projectfile context
Feature functions
Practical BIM review tools for IFC files
The implemented IFC toolbar includes model navigation, visibility controls, measurement, model tree access, properties and screenshot capture.
Fit model and fit selection
Section mode
Wireframe and x-ray views
Explode slider
Hide, isolate and show all
Distance and area measurement
Model tree and properties
Screenshot capture
Workflow
From IFC file to coordinated review
The viewer is loaded from the same project model workflow used by Plans, Documents and 3D records.
01
Open the project model
IFC files are routed to the shared IFC viewer engine instead of a generic download-only preview.
02
Inspect the right elements
Use selection, isolate, hide, properties and model-tree tools to focus the review on relevant objects.
03
Capture review context
Use measurement, area and screenshots when the model review needs to support coordination or issue discussions.
IFC review happens in the same project environment as the model record.
Screenshots
IFC model review in context
Show the model, switch review modes and use the tools that help construction teams inspect the file.
Model review view with browser-based IFC loading and project context.
Control visibility
Hide, isolate, x-ray, section and explode views help teams see the model from useful angles.
Inspect object context
Model tree and properties tools give reviewers more than a static visual preview.
Connected ArchiMesh modules
Model viewing belongs with project records
IFC files connect with document control, Autodesk model workflows, clash reporting and project search.
Review IFC models without leaving the project.
ArchiMesh connects IFC viewing with project files, records, BIM workflows and team coordination.
