Quantity Take-Off from project plans

Upload PDF or image drawings, set the plan scale, create grouped take-off items and measure counts, lengths and areas directly over the plan viewer.

PDFand image plans

Scaledmeasurements

Groupedtake-off items

PDF and image plan upload

Plan and item groups

Line measurement

Area measurement

Count markings

Marking color and style controls

Workflow

From drawing upload to measured quantities

The workflow matches the actual QTO module structure: plans first, then take-off items, then markings over the selected drawing.

Create plan records from PDF or image files and organize them with plan groups.

Apply the plan scale and create take-off groups and items with units such as pieces, linear meters or square meters.

Place count, line or polygon markings and keep their points stored against the selected item and plan.

Measured markings sit directly on the drawing so the quantity can be checked visually.

Plan viewer with take-off controls and drawing context.

Visual markings make it easier to check where a quantity came from.

Plan and take-off groups prevent a measurement package from becoming a flat list of files and items.

Structured quantities can support cost control, procurement and Bill of Quantities workflows.

ArchiMesh connects plan files, measurements, commercial records and project reporting in one construction platform.
